Diesel Scissor Lift Aerial Skylift 12m Mobile Lifter Scaffolding Electric Hydraulic Scissor Lift

Name: Diesel Scissor Lift Aerial Skylift 12m Mobile Lifter Scaffolding Electric Hydraulic Scissor Lift
Brand: LUHONGDA
Price: 1 USD

Quality Diesel Scissor Lift Aerial Skylift 12m Mobile Lifter Scaffolding Electric Hydraulic Scissor Lift for sale

Condition : New

Wheelbase : 2400mm

Model Number : 12m Hydraulic Scissor Lift

Brand Name : LUHONGDA

Place of Origin : Shandong, China

Applicable Industries : Construction works , Food & Beverage Shops, Building Material Shops, Machinery Repair Shops, Advertising Company, Manufacturing Plant, Energy & Mining, Food Shop, Retail

drive speed-raised : 0-10m/min

drive speed-stowed : 0-30m/min

Gradeability : 0.25

Ground clearance : 0.3 m

Height- stowed : 2m

Lift capacity on the extension : 1000kg

Lifting/lowering speed : 80/90 sec

Material : Other

Max platform height : 12m

max. platform occupancy : 2 pers

min.Turning radius (inside) : 2.8m

min.Turning radius (outside) : 3m

Overall Length : 3000mm

Overall Width : 2200mm

Platform length-extended : 3000mm

Power Souce : Diesel Engine

Table Size : 2700mm*1300mm

Total weight : 4300kg

Weight : 4300kg

Width : 2200mm

Safe Working Load : 500 kg

Total Extension Length (Left/Right) : 0.9 m

Safe Working Load on Extended Platform : 113 kg

Overall Length (Approx.) : 3000 mm

Overall Width (Approx.) : 2200 mm

Overall Height (Unfolded Guardrail) : 2700 mm

Overall Height (Folded Guardrail) : 2000 mm

Working Platform Size (L x W) : 2700 mm x 1300 mm

Minimum Ground Clearance (Retracted) : 0.3 m

Minimum Turning Radius (Inner Wheel) : 2.8m

MOQ : 1 set

Contact Now

Diesel Scissor Lift Aerial Skylift 12m Mobile Lifter Scaffolding Electric Hydraulic Scissor Lift

Parameter	Value
Safe Working Load	500 kg
Total Extension Length (Left/Right)	0.9 m
Safe Working Load on Extended Platform	113 kg
Maximum Number of Workers	2
Maximum Working Height	14 m
Maximum Platform Height	12 m
Overall Length (Approx.)	3000 mm
Overall Width (Approx.)	2200 mm
Overall Height (Unfolded Guardrail)	2700 mm
Overall Height (Folded Guardrail)	2000 mm
Working Platform Size (L x W)	2700 mm x 1300 mm
Minimum Ground Clearance (Retracted)	0.3 m
Minimum Turning Radius (Inner Wheel)	2.8 m
Minimum Turning Radius (Outer Wheel)	3 m
Travel Speed (Retracted)	0-30 m/min
Travel Speed (Raised)	0-10 m/min
Ascending/Descending Speed	80/90 sec
Maintenance-Free Batteries (8 pcs)	6V each, 200Ah
Maximum Climbing Ability	0.25
Tires	278.515
Total Weight (Approx.)	4300 kg

Q1: What is the maximum load capacity of this lift platform? A: The maximum load capacity of this lift platform typically ranges from 500 kg. Customers can select the appropriate model based on their specific needs. Q2: How long is the battery life of the platform? A: On a full charge, the battery life usually lasts between 4 to 8 hours, depending on the load and usage conditions. For long-term use, it is recommended to recharge the battery regularly to ensure proper functioning. Q3: Is this lift platform suitable for indoor use? A: Yes, this lifting platform is suitable for indoor use, especially the battery-powered versions, which do not emit harmful gases, making it ideal for enclosed or semi-enclosed spaces. Ensure the workspace is well-ventilated. Q4: How should I maintain and service the platform? A: Regular maintenance includes checking the battery, hydraulic system, tires, and safety devices to ensure the platform is free from damage or malfunction. Perform a full inspection once a month, including cleaning and lubricating moving parts, to ensure the equipment runs smoothly. Refer to the product manual for detailed maintenance instructions. Q5: What types of terrain can the platform's wheels handle? A: The platform is equipped with sturdy wheels designed for smooth operation on flat, hard surfaces. For rough or uneven terrain, we recommend choosing a model with larger wheels for better stability and mobility. Q6: Is the platform stable when raised to the maximum height of 12 meters? A: Yes, the platform remains stable at the maximum lift height of 12 meters, thanks to its multi-point support and safety systems. However, it is important to avoid excessive swaying or using the platform on unstable ground to maintain optimal stability.
